Plywood Eps Foam Polysyrene Aluminum Styrofoam 4 Axis Cnc Milling Machine Cnc Router

Brand : UnionTech
Model : UT-1325 EPS CNC Router
Category : EPS / Foam CNC Router
Price Range : $8000 to $15000 / Set
Payment Terms : T/T/Visa/Mastercard/American Express/Discover cards.
After-sale Service : Free professional machine operation training.
Supply Ability : 50 Sets per Month
Tel:+86 15562667312
Email:bill@union-cnc.com
WhatsApp:+86 15562667312
Parameter
Parts
Applications



  1. Big steel tube structure, so the machine’s body is strong, reliable and durable.

  2. Top-quality components, which makes the machine high-precision and high-efficiency. CSK guide rails, TBI ball screw, Richauto control system and so on, which keep the machine in best condition even after working for many years.

  3. Humanized and beautiful designing. Breakpoint specific memory to keep the carving status when power off, processing time forecast and other functions in case of the accidental power outages.  Emergency Stop Buttons , emergent shutdown during unexpected accidents and do no harm to human. Colorful machines’ appearances and high-quality paint make the machine beautiful.

  4. Easy and safe operation and low maintenance cost. To make you learn quickly how to operate safely the machine, free training in our factory will be offered. Less time and less money will be cost on the maintenance.

  5. Many optional configuration and OEM service available. According to your requirement, different configurations will be offered. OEM service is available for you.




ModelUT-1325EPS
Working area1300*2500*800mm (can be customized)
Working Voltage380V, 3PHASE, 50HZ (can be customized)
Control SystemDSP A18 control system
Spindle5.5KW water cooling spindle, ER25
Spindle speed0-24000RPM
Motor and DriverLeadshine easy servo driver and servo motor
Inverter5.5kw Fuling inverter
StructureHeavy duty thicker and bigger welded frame and gantry
Table surfaceAluminum Working Table with T-slot
Gantry structureThicker steel tube, Gantry Moving
CalibrationAuto tool sensor calibration
TransmissionX,Y Axis: Helical rack pinion, Z Axis: Taiwan TBI Ball Screw, Taiwan HIWIN/PMI/CSK 25# Rail Linear Bearing,
Command languageG Code
SoftwareArtCam, Ucancam,Type3
Rotary device:500mm diameter* 2500mm length
OptionalServo motor,4axis turning spindle




PRODUCT DESCRIPTION



  1. Big steel tube structure, so the machine’s body is strong, reliable and durable.

  2. Top-quality components, which makes the machine high-precision and high-efficiency. CSK guide rails, TBI ball screw, Richauto control system and so on, which keep the machine in best condition even after working for many years.

  3. Humanized and beautiful designing. Breakpoint specific memory to keep the carving status when power off, processing time forecast and other functions in case of the accidental power outages.  Emergency Stop Buttons , emergent shutdown during unexpected accidents and do no harm to human. Colorful machines’ appearances and high-quality paint make the machine beautiful.

  4. Easy and safe operation and low maintenance cost. To make you learn quickly how to operate safely the machine, free training in our factory will be offered. Less time and less money will be cost on the maintenance.

  5. Many optional configuration and OEM service available. According to your requirement, different configurations will be offered. OEM service is available for you.




ModelUT-1325EPS
Working area1300*2500*800mm (can be customized)
Working Voltage380V, 3PHASE, 50HZ (can be customized)
Control SystemDSP A18 control system
Spindle5.5KW water cooling spindle, ER25
Spindle speed0-24000RPM
Motor and DriverLeadshine easy servo driver and servo motor
Inverter5.5kw Fuling inverter
StructureHeavy duty thicker and bigger welded frame and gantry
Table surfaceAluminum Working Table with T-slot
Gantry structureThicker steel tube, Gantry Moving
CalibrationAuto tool sensor calibration
TransmissionX,Y Axis: Helical rack pinion, Z Axis: Taiwan TBI Ball Screw, Taiwan HIWIN/PMI/CSK 25# Rail Linear Bearing,
Command languageG Code
SoftwareArtCam, Ucancam,Type3
Rotary device:500mm diameter* 2500mm length
OptionalServo motor,4axis turning spindle
