• Technical Parameters:



    Model

    UT6090B

    Working area

    600*900*200mm (can be customized)

    Working Voltage

    220V, 3PHASE, 60HZ (can be customized)

    Control System

    Mach3 control system

    Spindle

    2.2KW HQD water cooling spindle

    Spindle speed

    0-24000RPM/MIN

    Motor and Driver

    Leadshine stepper and driver

    Inverter

    Fuling inverter

    Rotary axis

    Yes

    Structure

    Cast iron

    Table surface

    T-slot

    Gantry structure

    Gantry Moving

    Transmission

    3 Axis: Taiwan TBI Ball Screw

    Command language

    G Code

    Software

    ArtCam, JdPaint,Type3

    Applications

    Wood, MDF, PVC, Acrylic, Leather, Carpet,   Carton, Rubber, Corrugated box, Foam, Leather strip.

    Optional

    RichAuto DSP A11 controller


  • Parts of mini desktop cnc router 6090



    Leadshine stepper motor mach3 control systemwater cooling spindle

    Hiwin square railsTBI ball screw Fuling inverter


  • Applications:



    Used in advertising line, shoes’ moulding making and etc.



    It can process aluminum, pvc, acrylic, pcb, mdf, stone, etc.



    Well suited for processing panel. insulating materials, plastic, expoxy resin. carbon mixed compound, etc.



mini desktop cnc router 6090

desktop model

working area:600*900mm

2.2kw water cooling spindle

mach3 control system
