• Model

    UT6090 A2

    Working area

    600*900*300mm (can be customized)

    Working Voltage

    220V, 1PHASE, 50HZ (can be customized)

    Control System

    Mach3 control system

    Spindle

    3KW HQD air cooling spindle

    Spindle speed

    0-18000RPM/MIN

    Motor and Driver

    Leadshine stepper and driver

    Inverter

    Fuling inverter

    Structure

    Cast iron

    Table surface

    T-slot

    Gantry structure

    Gantry Moving

    Transmission

    X, Y axis: Helical rack pinions,

    Z axis: TBI ball screw

    Command language

    G Code

    Software

    ArtCam, JdPaint,Type3

    Applications

    Wood, MDF, PVC, Acrylic, Leather, Carpet,   Carton, Rubber, Corrugated box, Foam, Leather strip.

    Optional

    RichAuto DSP A11 controller




  • Parts of 6090 cnc router

    Leadshine stepper motor and driver

    NK105 control system

    Air cooling spindle

    Hiwin square rails

    TBI ball screw

    Fuling inverter


  • Application of UT6090 A2 cnc router:

    • It is engraving on brass, aluminum, plastic, acrylic, wood, MDF and other similar materials ;

    • Especially for Advertising industry:Advertising identification, sigh making, Acrylic engraving and cutting, Crafts processing,

      •    PVC words,Light words,Plastic words,Artwork,Aluminum,PCB, etc.



New 6090 router 4th axis
UT6090 A2 series
