automatic loading and unloading cnc router

Model	UT1325-S1
Type	Automatic loading and unloading
Working area	13002500200mm (can be customized)
Working Voltage	220V, 1PHASE, 50HZ (can be customized)
Control System	Taiwan Syntech control system
Control box	Independent control box
Spindle	9KW ATC air cooling spindle
Tools’ magazine	8 tools, Disc type
Spindle speed	0-18000RPM
Motor and Driver	Yaskawa servo motor and driver
Inverter	Taiwan Delta inverter
Structure	Heavy duty structure
Table surface	T-slot and Vacuum Working
Gantry structure	Gantry Moving
Vacuum pump	7.5kw water cooling vacuum pump (380V, 3PHASE, 50HZ)
Calibration	Automatic tool sensor calibration
Automatic lubrication system	Yes
Automatic positioning	Yes
Transmission	X,Y Axis: Helical rack, Taiwan Hiwin/PMI/ABBA 20# Rail Linear Bearing Z Axis: Taiwan TBI Ball Screw
Command language	G Code
Software	U.S. CV/ Chinese Yunxi
Optional	5+4 Vertical drilling head

Mechanical part of the machine ______ 1 set
Spindle Motor 9KW _______________ 1 piece
CNC electronic control box _________ 1 piece
Control System__________________ 1 piece
Vacuum pump (for the vacuum table)__1 piece
Dust collector (3kw double packages)__1 piece

Tool Box Parts:
Tool box ——————— 1 piece
Adjusting screw ———— 4 pieces
Clamp———————— 8 pieces
Collets———————— 4 pieces
Tool, bit, cutter, mill——–21 pieces
Spanner———————- 4 pieces
Software CD—————–1 piece
fuse core———————-2 pieces
Applications:
Furniture: Panel furniture, including kitchen cabinets, wardrobe, shelves, solid wooden furniture and etc.
Functions: pre-milling, cutting, making slot, vertical drilling

Samples:



automatic loading and unloading system

vertical drilling

making slot

9kw HSD spindle
