• Technical Parameters:


    Model

      UT-2050ATC

    Working area

      2000*5000*200mm (can be customized)

    Working Voltage

      380V, 3PHASE, 50HZ (can be customized)

    Control System

      Ncstudio control system

    Control box

      Computer control box

    Spindle

      9KW air cooling spindle

    Spindle speed

      0-24000RPM

    Motor and Driver

      YASKAWA servo driver and motor

    Inverter

      11kw Fuling inverter

    Structure

      Heavy duty thicker and bigger welded frame and gantry

    Table surface

      T-slot and Vacuum Working Table with 8 zones

    Gantry structure

      Thicker steel tube, Gantry Moving

    Vacuum pump

      11kw water cooling vacuum pump (380V, 3PHASE, 50HZ)

    Calibration

      Auto tool sensor calibration

    Transmission

      X,Y Axis: Helical rack pinion, Taiwan Hiwin/PMI/CSK 20# Rail Linear   Bearing, Z Axis: Taiwan TBI Ball Screw

    Command language

      G Code

    Software

      ArtCam, Ucancam,Type3

    Optional

      Servo motor,

      Rotary device: 200mm diameter* 2000mm length


  • Easy Operation Automatic Tools Changer ATC CNC Router Woodworking Machinery For Wood MDF PVC ACP CNC Router



       Spindle:

       World best brand Italy HQD 9kw air cooling

       spindle. ISO30 tool holder.
       Good qualiy and high precision. 11kw for options.


       Motor:
       Japanese YASKAWA servo

       motor 1kw.

    Easy Operation Automatic Tools Changer ATC CNC Router Woodworking Machinery For Wood MDF PVC ACP CNC Router
    Easy Operation Automatic Tools Changer ATC CNC Router Woodworking Machinery For Wood MDF PVC ACP CNC Router

       Auto tool changer:
       Linear type auto tool changer with 8 tools.

    10/12/16 tools for option.

    Controller :



    Taiwan professional LNC brand control system.

    Easy for a new operator.

    Easy Operation Automatic Tools Changer ATC CNC Router Woodworking Machinery For Wood MDF PVC ACP CNC Router




  •






    1. WoodFurniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen,craft sash,

    composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.

    2. Advertising industry: advertising identification, sigh making, Acrylic engraving and cutting,crystal word making, blaster molding, and other advertising materials derivatives making.

    3. Die industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble,plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.

    4. relief sculpture, 3D engraving & Cylinder object engraving.



UT-2050 Wood ATC CNC Router
