• Parameters:

    Model

    UT2030 door making atc cnc router machine

    Working area

    2000*3000*200mm (can be customized)

    Working Voltage

    380V, 3PHASE, 50HZ (can be customized)

    Control System

    SIEMENS 808D control system

    Control box

    Imported Rittal control box

    Spindle

    Chinese 9KW HQD air cooling spindle

    Spindle speed

    0-18000RPM

    Motor and Driver

    SIEMENS 1kw servo driver and motor

    Inverter

    11kw Fuling inverter

    Structure

    Heavy duty thicker and bigger welded   frame and gantry

    Table surface

    T-slot and Vacuum Working Table with 6   zones

    Gantry structure

    Gantry Moving

    Electric parts

    French Schneider brand

    Vacuum pump

    7.5kw water cooling vacuum pump (380V,   3PHASE, 50HZ)

    Calibration

    Auto tool sensor calibration

    Transmission

    X,Y Axis: Helical rack, Taiwan PMI 25#   Rail Linear Bearing

    Z Axis: Taiwan TBI Ball Screw

    Command language

    G Code

    Software

    ArtCam, JdPaint,Type3

    Optional

    Rotary device: 200mm diameter* 2000mm   length


  • Machine details:

    9kw Chinese HQD air cooling spindleGermany SIEMENS 808D control systemSIEMENS 1kw servo motor

    Auto tool sensorBigger and wider tow lineCarousel tool storage with 12 tools


    Cyliners for positionPMI25 guide rails


  • Applications:


    1. Woodworking: wooden door and furniture, windows, tables and chairs,cabinets and panels, 3D wave plate,MDF,computer desk,musical instruments, etc;


    2. Advertising: billboard, logo,sign,3D characters cutting,acrylic cutting,LED/neon channel,literal-hole cut,lightbox mold,stamp,mould,etc;


    3. Die industry: copper sculpture,aluminum engrave,metal molds,plastic sheeting,PVC ,etc;


    4. Decoration::acrylic, density board, artificial stone, organic glass, soft metals like aluminum and copper, et.



2030 atc cnc router

Model: UT-2030ATC
