• Parameters:


    Model

    UT-2040F

    Working area

    2000*4000*900mm (can be customized)

    Working Voltage

    380V, 3PHASE, 50HZ (can be customized)

    Control System

    Syntec control system

    Spindle

    Italy HSD 9kw air cooling spindle

    4 axis

    The spindle can rotate 180 degree with   servo motor

    Spindle speed

    0-18000RPM

    Motor and Driver

    YASKAWA servo driver and motor

    Inverter

    11kw Fuling inverter

    Structure

    Heavy duty thicker and bigger welded   frame and gantry

    Table surface

    Aluminum working table with T-slot

    Gantry structure

    Gantry Moving

    Machine structure

    Separated structure, with stable gantry   support

    Calibration

    Auto tool sensor calibration

    Transmission

    X,Y Axis: Helical rack, Taiwan Hiwin/PMI/ABBA   30# Rail Linear Bearing

    Z Axis: Taiwan TBI Ball Screw, HIWIN 30   rails with fixed slider

    Command language

    G Code

    Rotary device

    300mm diameter* 2000mm length


  • Machine details:


    9kw Italy HSD ATC spindleSyntec control systemMachine structure

    Working tableServo motor with reducerZ axis transmission


  • Applications:


    Suitable for EPS(expanded polystyrene) and styrofoam products making, such as theater props, arts&crafts, accessories mold, architectural shapes, interior crown molding, concrete forms&block-outs, dock&marine EPS floatation etc.


    Wooden ship model, wooden model aviation, trains and other wooden mold.


    Musical instrument industry:

    Three dimension musical instrument,contour cutting.


    Suitable Material:

    Wood, EPS and non-metallic carbon hybrid materials.



cnc router for foam

Model: UT-2040F


Sculpture various large non-metallic mold can be particularly suitable automotive foam mold, wooden ship model, wooden model aviation, trains and other wooden mold.
