Movement type

Gantry moving

Working area

2500*1300*900MM(can be customized)

Tavelling

A Axis--swing spindle,

B axis--Rotary device

C axis--Rotation table

Spindle

Chinese water cooling spindle

Working voltage

AC 3P 380V 50HZ(can be customized)

Control system

Syntec control system

Material of table

Aluminum profile

Material fixed type

T-Slot

Output power of spindle

7.5KW

Spindle speed

0-24000 R/M

Motor and driver

Syntec Servo motor and driver

Inverter

Fuling inverter

Table surface

T-slot Working Table with PVC

Cutter specifications

ER32, 20mm diameter

Maximum speed:

X Axis 40m/min

Y Axis 40m/min

Z Axis 20m/min

C Axis 2700°/min

A Axis 2700°/min

Programming Software

Powermill

Calibration

Manual tool sensor calibration

Equipment data storage and capacity

Cable transmission,USB,CF

Command language

G Code

Minimum   training period for operator

1 week
