• ODM Service:

    As a cnc machinery manufacturer in China for many years, we can design and produce the machinery to your requirment.

    Quality  Guarantee:

    We offer 12 months warranty for whole machine and half year warranty for spindle.


    Features of Cutter:

    • Effective working area: 1800*2600*200mm
    • Heavy duty thicker structure
    • Servo motor
    • Helical rack & Gear
    • Taiwan TBI ball screw
    • CSK25 square linear guide way for X, Y, Z axis
    • Oscillating knife+6kw air cooling spindle

    Parameters:

    ModelUT-1826OS
    X,Y axis travelling1300*2500mm/1800*2600mm
    Z axis travelling200mm/300mm/400mm
    Spindle 6kw air cooling spindle, ER32
    Inverter7.5kw Fuling/DELTA
    Control systemTaiwan LNC/Syntec/UnionTech
    Driving systemJapanese YASKAWA servo motor
    Working tableAluminum T-slot and Vacuum table
    Position cylindersYes, X2, Y3
    Transmission

    X,Y axis: Taiwan helical racks and pinion,

    Z axis: Taiwan ball screw,

    Compatible softwareArtcam, Aspire, AlphaCAM, Fusion 360, etc.
    Command languageG code & M code
    Travelling speed80m/min
    Working speed0-20m/min
    Working air requested≥0.7Mpa
    Working accuracy±0.03mm
    Working voltage

    220V,1ph/3ph, 50/60Hz.

    380V,3ph,50/60Hz



    Optional Items:

    Vacuum pump

    Water circulation pump,

    Rotary vane pump,

    Air pump,

    Germany Becker pump

    Dust collect system

    3kw/5.5kw/7.5kw, double/four bags.

    Air compressor

    Piston air compressor,

    Screw air compressor

    Protection deviceInfrared light curtain
    CameraCCD camera



  • 配件.png



  • 1. Wood furniture industry



    Doors; Cabinets; Tables; Chairs.

    Wave plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.

    2. Advertising industry



    Signage; Logo; Badges; Display board; Meeting sign board; Billboard

    Advertising filed, sign making, acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.

    3. Die industry



    A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand , plastic sheeting, PVC pipe, and other non-metallic mold.

    4. Artwork and Decoration



    wood crafts; gift box; jewelry box

    5. Others



    Relief sculpture and 3D engraving and Cylindrical object.

    sample knife.png



Oscillating Vibrating Knife Digital Cutting Machine
LOCATION : HOME - PRODUCTS - Digital Cutter
Brand : UnionTech
Model : UT-1826OS
Category : Oscillating CNC Router
Price Range : $5000 to $12000 / Set
Payment Terms : T/T/Visa/Mastercard/American Express/LC.
After-sale Service : Free professional machine operation training.
Supply Ability : 100 Sets per Month
