shoe mouldling making cnc router for aluminum

working area:600*600*200mm

cast iron structure with half enclosure

Parameter

Parts

Applications

Technical Parameters:

Model	UT6060M
Working area	600600200mm (can be customized)
Working Voltage	220V, 1PHASE, 50HZ (can be customized)
Control System	Mach3 control system
Spindle	2.2KW HQD GDK constant power spindle
Spindle speed	9000-18000RPM/MIN
Motor and Driver	Leadshine easy servo motor and driver
Inverter	Fuling inverter 3.7kw
Rotary axis	Yes
Structure	Cast iron
Table	Cast table
Gantry structure	Table moving
Transmission	3 Axis: Taiwan TBI Ball Screw
Command language	G Code
Software	ArtCam, JdPaint,Type3
Applications	Wood, MDF, PVC, Acrylic, Leather, Carpet, Carton, Rubber, Corrugated box, Foam, Leather strip.
Optional	RichAuto DSP A11 controller

Parts of mini 6060 cnc router for metal

cast iron structure	GDK metal spindle with constant power	Mach3 controller

Hiwin square rails	cast iron gantry	oil spray system for metal
