Movement type

Table moving

Working area

3100*1600*900MM(can be customized)

Tavelling

C Axis ±213°

A Axis ±120°

Beam space

2750MM

Beam Height

1500MM

Double pendulum head type

HS652

Brand of double pendulum head

Italy HSD

Working voltage

AC 3P 380V 50HZ(can be customized)

Control system

OSAI control system

Material of table

Aluminum profile

Material fixed type

T-Slot

Output power of spindle

12KW

Spindle speed

0-24000 R/M

Motor and driver

Japan YASKAVA Servo motor and driver

Inverter

Delta inverter

Table surface

T-slot and Vacuum Working Table with 4   zones

Magazine

Disc magazine tool (8 positions)

Cutter specifications

HSK.F63.ER40

Maximum speed:

X Axis 40m/min

Y Axis 40m/min

Z Axis 20m/min

C Axis 2700°/min

A Axis 2700°/min

Programming Software

AlphaCAM V7 version

Calibration

Manual tool sensor calibration

Total Power(KW)

30KW

Equipment data storage and capacity

Cable transmission,USB,CF

Command language

G Code

Minimum   training period for operator

2 weeks

Machine size

4260*2150*3300MM

Total weight

12T
