•  Features:

    • Italy HSD air cooling spindle,

    • Heavy duty machine structure,

    • Taiwan DELTA inverter,

    • Professional Taiwan Syntec control system,

    • Japanese YASKAWA servo motor,


    • Parameters:

    • Model
      UT-2080ATC
      Working area
      2000*8000*200mm
      Working voltage
      380V, 3ph, 50-690Hz ( 220V, 1ph for option)
      Control systemSyntec control system
      Spindle
      Italy 9kw ATC air cooling spindles
      InverterTaiwan DELTA inverter
      Motor and driver
      Japanese YASKAWA servo driver and motor
      X,Y,Z Repositioning Accuracy±0.03mm
      Structure
      Heavy duty bigger and thicker steel tube
      Working table
      Vacuum table with T-slot
      Lubrication systemAuto
      X, Y StructureGear and rack transmission, TBI Linear Rail
      Z StructureTaiwan TBI Ball Screw, TBI25 Linear Rail
      Command LanguageG code
      Computer InterfaceUSB interface
      Auto tool changerCarousel auto tool changer with 12 tools


  • Machine details:

    Italy HSD 9kw ATC air cooling spindleCarousel auto tool changer, 12 toolsSyntec 6MB control system

    YASKAWA servo motorSchneider electric partsOil cooling pump


  • 1. Wood furniture industry


    Doors; Cabinets; Tables; Chairs.


    Wave plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.


    2. Advertising industry


    Signage; Logo; Badges; Display board; Meeting sign board; Billboard


    Advertising filed, sign making, acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.


    3. Die industry


    A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand , plastic sheeting, PVC pipe, and other non-metallic mold.


    wood crafts; gift box; jewelry box


    4. Others


    Relief sculpture and 3D engraving and Cylindrical object.


    The machine is expecially for large size fiberglass, acrylic, aluminum, ACP board cutting.



large size ATC cnc router for fiber glass cutting
2080ATC cnc router
